Description

• Supports HDMI 1.3.
• Follow standard IEEE-568B.
• Can extend HDMI 1080p signal to 60m.
• Support up to 20m cable length between the extender and the source device when use HDMI/AWG26 cable.
• Indicator LED can indicate the working status.
• Allows you control a DVD player or other HDMI video source from a remote location with the included IR cables.
• Automatic adjustment to match cable length.
• Installs in minutes. No need driver. Plug and play.
• Long distance transmission of high definition signals is very difficult because HDMI cable is very expensive and infrequent. This HDMI extender breaks the problem of the expensive HDMI cable transmission distance, simply use one network cat6/cat6a/cat7 cable in stead of HDMI cable to extend HDMI signal to 60m , saving your money and space.

Specification：

• Support HDCP Version HDCP1.2
• Support HDMI Resolution 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
• Transmit Length more than 60m by CAT6 Cable or higher level cable
• Support Network Cable CAT6, CAT6A, CAT7
• Power Supply DC5V 1A 2pcs
• Support IR remote control 20-60Khz
• Power Consumption TX: 2W; RX Less than 2W
• Operating Temperature 0～60 Celsius
• Weight 105g*2pcs
• Color :Black
• Plug Type:EU Plug
• Plug Type:EU Plug,it applies to Indonesia, Germany, France, Spain, Italy and so on.
• Material:Aluminum alloy
• size:66.8x82.6x21.3mm

Package Contents:

• 1*HDMI to RJ45 sender TX
• 1*RJ45 to HDMI receiver RX
• 2*DC5V/1A Power Adapter
• 1*1*IR blaster extension cable
• 1*IR receiver extension cable
• 1*User Manual
