Feature

• Color: Black
• Material: Plastic and Zinc Alloy
• Size: Approx. 68 * 56.3 * 20.5mm
• HDMI: 1.4b
• HDCP: 1.4
• Audio sampling rate: 32 ~ 192 KHz
• HDMI transmission bandwidth: 300 MHz(Max)
• HDMI transmission speed: 10.2 Gbps(Max)
• Input TMDS signal: 0.5 ~ 1.5Vp-p (TTL)
• Input DDC signal: 5Vp-p (TTL)
• RCA analog output (1 KHz 0dB): 1 V RMS
• Distortion: ≤ 0.1%
• HDMI Input Resolution Supported: 2160P(Max), 1080P, 720P, etc.
• Video output format: NTSC\PAL

• Convert HDMI video signal to CVBS(AV) signal. Applicable to TV, VHS VCR, DVD recorders, etc.

• Compatible with HDMI 1.4, supports both PAL and NTSC output with a select switch.

• Plug and play. There is no need to install drivers or softwares to run it.

• Note: This converter only converts HDMI to RCA! NOT A TWO WAY CONVERTER.

Package

• 1 x Converter
• 1 x Manual
• 1 x Cable
