Mini Hifi Audio Decoder Amp Support Coaxial Spdif/Optical Input 6.35Mm Earphone Rca Audio Output Amplifier For Tv DVD
Sku
UIQN0040
$33.62
| Qty | 1 | 2 | 5 | 10 | 20 |
|---|---|---|---|---|---|
| Price | $36.42 | $35.92 | $35.02 | $34.23 | $33.62 |
Qty
Sales Ends In
- Buyer Protection
- Full Refound if you don't receive your order
- Full or Partial Refund,If the item is not as described
Specifications:
- Model Number: XU20
- Chip: DIR9001
- Interface input: Coaxial, SPDIF/Optical
- Interface output: RCA, 6.35mm Earphone Jack
- Sampling Rate: 44.1Hz/ 48KHz/ 88.2kHz/ 96KHz
- Bit Depth: 16bit/ 24bit
- Dynamic Range: 110dB
- Signal to Noise Ratio: 105dB
- Distortion: 0.001%
- Power consumption: 3W
- Amp output power:
- 32ohm 84mW at THD+N=0.1%
- 64ohm 69mW at THD+N=0.003%
- 150ohm 29mW at THD+N=0.001%
- 300ohm 14mW at THD+N=0.001%
- Input Voltage: AC 100-240V, 50/60Hz
- Power supply: DC+9V
- Color: Black
- Size: approx. 10.6*7*2.8
- Main Item Weight: approx. 199g / 7.01oz
Package List:
- 1 * Audio Decoder
- 1 * Power Adapter
- 1 * User Manual (English & Chinese)
- Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
